1.Water cooling reduces the heat generated in the drawing process and reducesMold loss, improve wire quality.
2.high quality of finished line, smooth surface, thickness uniform.
3.Tunasten carbide spray the drums. long service life
4.Hiah speed with inverter speed adiustable
Wire drawing processing for high, medium and low carbon steel wire, stainless steel wire, copper wire, alloy copper wire, aluminum alloy copper wire, etc
Type | LNSD9-900 | LNSD9-800 | LNSD9-700 | LNSD10-600 | LNSD10-400 |
Drum Dia./mm | 900 | 800 | 700 | 600 | 400 |
Drawing Passes/time | 9 | 9 | 9 | 10 | 10 |
Max.Inlet Wire Dia. mm | 8-14 | 8-10 | 6.5-8 | 5.5-6.5 | 1.8-2.5 |
Min.Outlet Wire Dia.mm | 3-5 | 3-4 | 2.5-3 | 1.8-2 | 0.75-1 |
Drawing Speed m/min | 300 | 360 | 480 | 750 | 840 |
Inlet Wire Strength kg/m² | ≤1300 | ≤1300 | ≤1300 | ≤1300 | ≤1300 |
Total Compressibility% | 85.94-87.24 | 84-85.94 | 85.21-85.94 | 89.29-90.53 | 87.24 |
Average Compressibility% | 19.58-20.48 | 18.42-19.58 | 19.13-19.58 | 21.00-21.02 | 18.61 |
Motor PowerkW | 90-110 | 55-90 | 22-37、 | 22-37 | 7.5-15 |
Weightkg | 9500 | ||||
Diamensionmm | 10000*1800*1300 | ||||
