The 3-14mm Reinforcing Mesh Welding Machine is a high-performance industrial solution engineered for the precision fabrication of heavy-duty welded wire mesh. Utilizing advanced synchronous CNC technology, this machine offers unparalleled control over welding time and sub-control processes, ensuring an intelligent, humane operation that significantly reduces manual labor while maximizing output consistency.
Designed for versatility and strength, the system can process mesh widths up to 3000mm with wire diameters ranging from 3mm to 14mm. Whether you require finished products in flat sheets or continuous coils, this machine provides the flexibility to handle both coil-fed (3-6mm) and bar-fed (5-14mm) line wires, making it an essential asset for large-scale construction and industrial infrastructure projects.
| Max Mesh Width | 2000mm / 2500mm / 3000mm | Mesh Length | 3-8m (Max 12m) |
|---|---|---|---|
| Mesh Type | By sheet or coil | Line Wire Spacing | 100-300mm |
| Cross Wire Spacing | 50-300mm | Wire Diameter | 3-12mm (up to 14mm) |
| Line Wire Type | 3-6mm (Coils) / 5-12mm (Bars) | Cross Wire Type | Bars |
| Welding Speed | 60-85 times/min | Electric Power | 185KVA x 5 / 6 / 8 |
High-pressure cylinders provide massive force at the welding point electrodes, ensuring deep penetration and strong solder joints.
Capable of 60-85 welding cycles per minute, allowing for rapid completion of large-volume industrial tasks.
Synchronous CNC technology guarantees accurate mesh dimensions and uniform welding spots across the entire sheet.
The integrated control system manages welding timing and sub-controls, making the workflow more intuitive and humane.
The finished mesh can be delivered as flat sheets or rolled into coils, with customizable cutting for specific project sizes.
Advanced control logic eliminates welding defects and ensures long-term stability under continuous operation.
Seamless integration of coil and bar feeding systems for various wire diameters.
Real-time synchronization between the feeding mechanism and welding heads.
Continuous tracking of welding current and pressure to prevent spot defects.
User-friendly interface for adjusting mesh spacing and welding parameters.
Automatic switching between sheet cutting and coil rolling modes.
Optimized power distribution via KVA transformers to reduce electricity waste.
| Feature | Traditional Manual Welding | Our CNC Welding Machine |
|---|---|---|
| Production Speed | Low / Variable | High (60-85 times/min) |
| Weld Consistency | Manual / Inconsistent | Precision CNC / Uniform |
| Labor Requirement | High Workforce | Minimal / Intelligent |
| Waste Rate | Significant Material Waste | Precision Cutting / Low Waste |
| Versatility | Limited to specific sizes | Wide Range (3-14mm diameter) |
The machine is designed to process wire diameters ranging from 3mm to 14mm, allowing for both lightweight and heavy-duty reinforcing mesh production.
Yes, the reinforcing mesh welding machine is flexible and can produce finished mesh in either sheet or coil form depending on your requirements.
It is widely used in the production of road and railway guardrails, fence nets, floor pouring roof nets, coal mine support nets, and various construction meshes.
CNC technology ensures synchronous control over the welding process, resulting in precise mesh sizes and uniform, firm welding spots that eliminate manual errors.
You can choose 3-6mm wire fed by coils or 5-14mm wire fed by bars, providing versatility for different raw material specifications.
Stability is achieved through large cylinder pressure and a high-current welding system, ensuring that every joint is securely fused and capable of withstanding industrial loads.
